Description
01
02
03
04
Strong versatility
ABS electrical interface
Internal components
Thread design
High RF versatility
Applicable to various occasions
Can detect particles, fly ash, electrical
conductivity
Non-conducting liquids, viscous materials
ABS moisture-proof and dustproof joint
Effective protection of internal lines
Ensure accurate
measurement
Long service life
Real-time monitoring, anti-adhesion design
Avoid material adhesion
Spurious error signal
No periodic cleaning
required
All stainless steel
It is not easy to rust after long-time use
Full range of
specifications and
customizable
RADIO.FREOUENCYADMITTANCE LEVEL METER
Stability independent of temperature
RF can detect all materials regardless of material density and particle size
Influence of change in parameters such as deposition viscosity and conductivity of chemical composition
Wide application range, long service life and wide application
SPLIT-TYPE RFADMITTANCE LEVEL METER
The split type RF admittance level gauge has strong practicality Suitable for various industrial occasions
Especially when high precision and Excellent performance in highly stable measurement environments
FLAT PLATE RFADMITTANCE LEVEL METER
1. Good stability, not affected by temperature
2. Applied to the detection of pulverized coal, syrup, solids,grains, and interfaces
CAPACITIVE LEVEL SWITCH
Capacitive level switch is compact in size PTFE anti-corrosion sleeve, sensitive to induction
In high viscosity, high pressure, and high adhesion media
There are strong application advantages in switch control measurement
It can also be made into continuous measurement with almost no blind spots
Anti attachment, not afraid of viscous materials
CAPACITIVE DIGITALDISPLAY LEVEL METER
Pole type and cable type. PTFE anti-corrosion sleeve, not afraid of corrosion
IP65 protection level, almost no blind spots, small range measuring tool
Single pole structure, not affected by various viscous materials attached
1
2
3
4
5
6
7
8
Fine sensitivity
adjustment
Probe status
indicator
Coarse sensitivity
adjustment
Alarm light
Alarm
time
adjustment
Alarm output
Mode switching
Switch alarm
output 1
Switch alarm
output 2
Product name
RF Admittance Level Meter
Power
3W
Sensitivity
0.3~750PF
Alarm Time Adjustment
Adjustable within the range of 0 to 30 seconds
Probe Length
500mm (default)
Alarm Type
Selectable Upper or Lower Limit
Protection Rating
IP65
Power Supply Voltage
220V AC/110V AC/24V AC/24V DC
Relay Output
5A/240V AC, Two Sets of Normally Open (NO) and Normally Closed (NC) Contacts
Connection Method
G1 Thread, Customizable Chuck Type or Flange Type (Default M27*2 for Capacitive)
Ambient temperature
-40℃~80 ℃; Temperature range: - 40~120 ℃, customizable high temperature type (max900 ℃)
Probe material
Default 304 stainless steel, customizable 316L, customizable Teflon spray coating or lined Teflon
Product name
Capacitive Level Meter
Withstanding Pressure Range
-1~320bar
Accuracy
0.2%FS/0.5%FS
Power Supply Voltage
15~36V D
Output signal
4~20mA
Stability
0.1%FS/year
Protection Rating
IP65
Probe material
Stainless steel/set of PTFE (customizable)
Measuring range
Pole type 300~5000mm; Cable type 2~20m (customizable)
Probe temperature resistance
-50℃~550 ℃; Ambient temperature: - 40~85 ℃; Storage temperature: - 50~+60 ℃
